| Product Information | |
|---|---|
| Brand | Tenways |
| Name | AGO X |
| Price | $1999 |
| Release Year | 2023 |
| Category | Commuter, Hybrid |
| Motor | |
| Motor Type | Mid-Drive |
| Motor Position | Mid |
| Motor Brand | Bafang |
| Motor Model | M410 |
| Power (Nominal) | 250W |
| Torque | 80 Nm |
| Assist Levels | 5 |
| Sensor Type | Torque |
| Battery | |
| Battery Capacity | 504 Wh |
| Voltage | 36V |
| Amp-hours | 14 Ah |
| Battery Position | Downtube |
| Removable Battery | Yes |
| Max Range | 62 miles |
| Charge Time | 6 hrs |
| Speed & Class | |
| Class | Class 1 |
| Top Assist Speed | 20 MPH |
| Throttle | No |
| Drivetrain | |
| Gears | 10 |
| Drive System | Chain |
| Derailleur | Shimano 10-speed |
| Cassette | 11-46T |
| Shifter | Trigger |
| Brakes | |
| Brake Type | Hydraulic Disc |
| Brake Brand | Tektro |
| Rotor Size (Front) | 180 mm |
| Rotor Size (Rear) | 180 mm |
| Frame & Geometry | |
| Frame Material | Aluminum |
| Frame Style | Step-Over |
| Sizes Available | M, L, XL |
| Min Rider Height | 63" |
| Max Rider Height | 77" |
| Total Length | 74.7" |
| Min Handlebar Height | 37" |
| Max Handlebar Height | 44" |
| Min Seat Height | 33.1" |
| Max Seat Height | 39.4" |
| Wheelbase | 45.1" |
| Handlebar Width | 27.2" |
| Wheels & Tires | |
| Wheel Size | 29" |
| Tire Width | 2.25" |
| Tire Brand | CST |
| Tire Type | Hybrid |
| Puncture Protection | Yes |
| Suspension | |
| Front Suspension | None |
| Front Travel | 100 mm |
| Rear Suspension | None |
| Seatpost Suspension | No |
| Dimensions & Weight | |
| Weight | 64 lbs |
| Weight Limit | 265 lbs |
| Rack Capacity | 55 lbs |
| Components | |
| Display | LCD |
| Connectivity | Bluetooth |
| App Compatible | Yes |
| Integrated Features | |
| Integrated Lights | No |
| Fenders | No |
| Rear Rack | No |
| Front Rack | No |
| Kickstand | No |
| Chain Guard | No |
| Walk Assist | No |
| Alarm | No |
| USB Charging | No |
| Bottle Cage Mount | No |
| Safety & Compliance | |
| IP Rating | IPX4 |
| Certifications | UL 2849, EN 15194 |
| Advanced Comparison | |
| Price vs. Weight | 31.23 $/lb |
| Price vs. Power (Nominal) | 8 $/W |
| Price vs. Torque | 24.99 $/Nm |
| Price vs. Battery | 3.97 $/Wh |
| Price vs. Range | 32.24 $/mile |
| Price vs. Assist Speed | 99.95 $/MPH |
| Price vs. Weight Limit | 7.54 $/lb |
| Price vs. Gears | 199.9 $/gear |
| Range vs. Weight | 0.97 mile/lb |
| Battery vs. Weight | 7.88 Wh/lb |
| Power vs. Weight | 3.91 W/lb |
| Torque vs. Weight | 1.25 Nm/lb |
