| Product Information | |
|---|---|
| Brand | Mokwheel |
| Name | Onyx |
| Price | $3288.88 |
| Release Year | 2025 |
| Category | Fat Tire |
| Motor | |
| Motor Type | Mid-Drive |
| Motor Position | Mid |
| Power (Nominal) | 750W |
| Power (Peak) | 1300W |
| Torque | 210 Nm |
| Sensor Type | Both |
| Battery | |
| Battery Capacity | 940 Wh |
| Voltage | 48V |
| Amp-hours | 19.6 Ah |
| Battery Position | Downtube |
| Removable Battery | Yes |
| Max Range | 80 miles |
| Speed & Class | |
| Class | Class 2, Class 3 |
| Top Assist Speed | 28 MPH |
| Throttle Top Speed | 20 MPH |
| Throttle | Yes |
| Drivetrain | |
| Gears | 10 |
| Drive System | Chain |
| Derailleur | Shimano |
| Shifter | Trigger |
| Brakes | |
| Brake Type | Hydraulic Disc |
| Brake Brand | Tektro |
| Brake Model | HD-E3940 |
| Rotor Size (Front) | 203 mm |
| Rotor Size (Rear) | 203 mm |
| Frame & Geometry | |
| Frame Material | Aluminum |
| Frame Style | Step-Over |
| Sizes Available | One Size |
| Min Rider Height | 67" |
| Max Rider Height | 81" |
| Total Length | 79" |
| Min Handlebar Height | 45.2" |
| Max Handlebar Height | 45.2" |
| Min Seat Height | 35" |
| Max Seat Height | 41" |
| Wheelbase | 50" |
| Handlebar Width | 28.3" |
| Wheels & Tires | |
| Wheel Size | 26" |
| Tire Width | 4" |
| Tire Type | Fat |
| Puncture Protection | Yes |
| Suspension | |
| Front Suspension | Air |
| Front Travel | 135 mm |
| Rear Suspension | Air |
| Rear Travel | 50 mm |
| Seatpost Suspension | No |
| Dimensions & Weight | |
| Weight | 89 lbs |
| Weight Limit | 400 lbs |
| Components | |
| Display | LED |
| Display Size | 3.1" |
| App Compatible | No |
| Integrated Features | |
| Integrated Lights | No |
| Fenders | No |
| Rear Rack | No |
| Front Rack | No |
| Kickstand | Yes |
| Chain Guard | No |
| Walk Assist | No |
| Alarm | No |
| USB Charging | No |
| Bottle Cage Mount | No |
| Safety & Compliance | |
| IP Rating | IPX4 |
| Certifications | UL 2849, UL 2271 |
| Advanced Comparison | |
| Price vs. Weight | 36.95 $/lb |
| Price vs. Power (Nominal) | 4.39 $/W |
| Price vs. Power (Peak) | 2.53 $/W |
| Price vs. Torque | 15.66 $/Nm |
| Price vs. Battery | 3.5 $/Wh |
| Price vs. Range | 41.11 $/mile |
| Price vs. Assist Speed | 117.46 $/MPH |
| Price vs. Weight Limit | 8.22 $/lb |
| Price vs. Gears | 328.89 $/gear |
| Range vs. Weight | 0.9 mile/lb |
| Battery vs. Weight | 10.56 Wh/lb |
| Power vs. Weight | 8.43 W/lb |
| Torque vs. Weight | 2.36 Nm/lb |
