| Product Information | |
|---|---|
| Brand | Jasion |
| Name | X-Hunter |
| Price | $899 |
| Release Year | 2023 |
| Category | Mountain, Folding, Fat Tire |
| Motor | |
| Motor Type | Hub |
| Motor Position | Rear Hub |
| Power (Nominal) | 750W |
| Power (Peak) | 1400W |
| Torque | 85 Nm |
| Assist Levels | 5 |
| Sensor Type | Unknown |
| Battery | |
| Battery Capacity | 624 Wh |
| Voltage | 48V |
| Amp-hours | 13 Ah |
| Battery Position | Integrated |
| Removable Battery | Yes |
| Max Range | 70 miles |
| Charge Time | 5.5 hrs |
| Speed & Class | |
| Class | Unknown |
| Top Assist Speed | 30 MPH |
| Throttle | Yes |
| Drivetrain | |
| Gears | 7 |
| Drive System | Chain |
| Derailleur | Shimano |
| Shifter | Trigger |
| Brakes | |
| Brake Type | Mechanical Disc |
| Rotor Size (Front) | 160 mm |
| Rotor Size (Rear) | 160 mm |
| Frame & Geometry | |
| Frame Style | Folding |
| Sizes Available | One Size |
| Min Rider Height | 63" |
| Max Rider Height | 76" |
| Total Length | 69" |
| Min Handlebar Height | 46" |
| Max Handlebar Height | 46" |
| Min Seat Height | 30" |
| Max Seat Height | 46" |
| Wheelbase | 46" |
| Handlebar Width | 25.2" |
| Wheels & Tires | |
| Wheel Size | 20" |
| Tire Width | 4" |
| Tire Type | Fat |
| Puncture Protection | Yes |
| Suspension | |
| Front Suspension | Air |
| Front Travel | 180 mm |
| Rear Suspension | None |
| Seatpost Suspension | No |
| Dimensions & Weight | |
| Weight | 71 lbs |
| Weight Limit | 400 lbs |
| Components | |
| Display | LCD |
| App Compatible | No |
| Integrated Features | |
| Integrated Lights | Yes |
| Fenders | Yes |
| Rear Rack | No |
| Front Rack | No |
| Kickstand | No |
| Chain Guard | No |
| Walk Assist | No |
| Alarm | No |
| USB Charging | No |
| Bottle Cage Mount | No |
| Safety & Compliance | |
| IP Rating | IPX6 |
| Advanced Comparison | |
| Price vs. Weight | 12.66 $/lb |
| Price vs. Power (Nominal) | 1.2 $/W |
| Price vs. Power (Peak) | 0.64 $/W |
| Price vs. Torque | 10.58 $/Nm |
| Price vs. Battery | 1.44 $/Wh |
| Price vs. Range | 12.84 $/mile |
| Price vs. Assist Speed | 29.97 $/MPH |
| Price vs. Weight Limit | 2.25 $/lb |
| Price vs. Gears | 128.43 $/gear |
| Range vs. Weight | 0.99 mile/lb |
| Battery vs. Weight | 8.79 Wh/lb |
| Power vs. Weight | 10.56 W/lb |
| Torque vs. Weight | 1.2 Nm/lb |
