| Product Information | |
|---|---|
| Brand | Giant |
| Name | Reign E+ 3 2023 |
| Price | $5310 |
| Release Year | 2022 |
| Category | Mountain |
| Motor | |
| Motor Type | Mid-Drive |
| Motor Position | Mid |
| Motor Brand | Giant |
| Motor Model | SyncDrive Pro |
| Power (Nominal) | 250W |
| Torque | 85 Nm |
| Sensor Type | Torque |
| Battery | |
| Battery Capacity | 800 Wh |
| Battery Position | Downtube |
| Removable Battery | Yes |
| Max Range | 86 miles |
| Speed & Class | |
| Class | Class 1 |
| Top Assist Speed | 20 MPH |
| Throttle | No |
| Drivetrain | |
| Gears | 12 |
| Drive System | Chain |
| Derailleur | Shimano Deore |
| Cassette | 10-51T |
| Shifter | Trigger |
| Brakes | |
| Brake Type | Hydraulic Disc |
| Brake Brand | Shimano |
| Brake Model | Deore BR-M420 |
| Rotor Size (Front) | 203 mm |
| Rotor Size (Rear) | 203 mm |
| Frame & Geometry | |
| Frame Material | Aluminum |
| Frame Style | Step-Over |
| Sizes Available | S, M, L, XL |
| Min Rider Height | 64" |
| Max Rider Height | 78" |
| Wheelbase | 48.7" |
| Handlebar Width | 31.5" |
| Wheels & Tires | |
| Wheel Size | 29" |
| Tire Type | Knobby |
| Puncture Protection | No |
| Suspension | |
| Front Suspension | Air |
| Front Travel | 170 mm |
| Rear Suspension | Air |
| Rear Travel | 160 mm |
| Seatpost Suspension | No |
| Dimensions & Weight | |
| Weight | 57.3 lbs |
| Weight Limit | 344 lbs |
| Components | |
| Display | LED |
| App Compatible | Yes |
| Integrated Features | |
| Integrated Lights | No |
| Fenders | No |
| Rear Rack | No |
| Front Rack | No |
| Kickstand | No |
| Chain Guard | No |
| Walk Assist | No |
| Alarm | No |
| USB Charging | No |
| Bottle Cage Mount | No |
| Safety & Compliance | |
| IP Rating | IPX2 |
| Advanced Comparison | |
| Price vs. Weight | 92.67 $/lb |
| Price vs. Power (Nominal) | 21.24 $/W |
| Price vs. Torque | 62.47 $/Nm |
| Price vs. Battery | 6.64 $/Wh |
| Price vs. Range | 61.74 $/mile |
| Price vs. Assist Speed | 265.5 $/MPH |
| Price vs. Weight Limit | 15.44 $/lb |
| Price vs. Gears | 442.5 $/gear |
| Range vs. Weight | 1.5 mile/lb |
| Battery vs. Weight | 13.96 Wh/lb |
| Power vs. Weight | 4.36 W/lb |
| Torque vs. Weight | 1.48 Nm/lb |
