| Product Information | |
|---|---|
| Brand | Aventon |
| Name | Abound SR |
| Price | $1899 |
| Release Year | 2024 |
| Category | Cargo |
| Motor | |
| Motor Type | Hub |
| Motor Position | Rear Hub |
| Power (Nominal) | 750W |
| Power (Peak) | 950W |
| Torque | 80 Nm |
| Assist Levels | 4 |
| Sensor Type | Torque |
| Battery | |
| Battery Capacity | 708 Wh |
| Voltage | 36V |
| Amp-hours | 20 Ah |
| Battery Position | Downtube |
| Removable Battery | Yes |
| Max Range | 60 miles |
| Speed & Class | |
| Class | Class 2 |
| Top Assist Speed | 20 MPH |
| Throttle Top Speed | 20 MPH |
| Throttle | Yes |
| Drivetrain | |
| Gears | 8 |
| Drive System | Chain |
| Derailleur | Shimano Altus |
| Cassette | 12-32T |
| Shifter | Trigger |
| Brakes | |
| Brake Type | Hydraulic Disc |
| Brake Brand | Tektro |
| Brake Model | HD-E3520 |
| Rotor Size (Front) | 180 mm |
| Rotor Size (Rear) | 203 mm |
| Frame & Geometry | |
| Frame Material | Aluminum |
| Frame Style | Step-Through |
| Sizes Available | One Size |
| Min Rider Height | 59" |
| Max Rider Height | 75" |
| Wheelbase | 45" |
| Handlebar Width | 26.8" |
| Wheels & Tires | |
| Wheel Size | 20" |
| Tire Width | 3" |
| Tire Brand | Aventon |
| Tire Type | Hybrid |
| Puncture Protection | Yes |
| Suspension | |
| Front Suspension | Air |
| Front Travel | 50 mm |
| Rear Suspension | None |
| Seatpost Suspension | Yes |
| Dimensions & Weight | |
| Weight | 80 lbs |
| Weight Limit | 440 lbs |
| Rack Capacity | 143 lbs |
| Components | |
| Display | LCD |
| Connectivity | Bluetooth, GPS |
| App Compatible | Yes |
| Integrated Features | |
| Integrated Lights | Yes |
| Fenders | Yes |
| Rear Rack | Yes |
| Front Rack | No |
| Kickstand | Yes |
| Chain Guard | No |
| Walk Assist | Yes |
| Alarm | Yes |
| USB Charging | No |
| Bottle Cage Mount | Yes |
| Safety & Compliance | |
| IP Rating | IPX6 |
| Certifications | UL 2849, UL 2271 |
| Advanced Comparison | |
| Price vs. Weight | 23.74 $/lb |
| Price vs. Power (Nominal) | 2.53 $/W |
| Price vs. Power (Peak) | 2 $/W |
| Price vs. Torque | 23.74 $/Nm |
| Price vs. Battery | 2.68 $/Wh |
| Price vs. Range | 31.65 $/mile |
| Price vs. Assist Speed | 94.95 $/MPH |
| Price vs. Weight Limit | 4.32 $/lb |
| Price vs. Gears | 237.38 $/gear |
| Range vs. Weight | 0.75 mile/lb |
| Battery vs. Weight | 8.85 Wh/lb |
| Power vs. Weight | 9.38 W/lb |
| Torque vs. Weight | 1 Nm/lb |
